The Elpress SC50R50S Shearbolt Connector is a high-performance solution designed for medium-voltage power applications (1–36 kV). Engineered to provide secure and reliable electrical connections, this connector is ideal for both aluminum and copper conductors of class 1 and class 2.

The connector is equipped with pre-threaded brass shear-off bolts, ensuring smooth installation with minimal friction and eliminating the need for crimping tools—standard wrenches are sufficient. The partition wall provides mechanical strength and ensures precise conductor positioning, resulting in a stable and long-lasting connection.

Supporting a wide range of conductor types, the SC50R50S accommodates:

• Round cables (10–50 mm², Cu RE 10–35 mm²)

• Sector-shaped cables (16–50 mm²)

For splicing copper screen conductors (6–35 mm²), the connector can be used together with the SC95N/PEN filler bit, ensuring seamless integration and optimized screen connection.

Built to the highest quality standards, the SC50R50S meets the requirements of IEC 61238-1:2003, guaranteeing excellent electrical conductivity, mechanical stability, and long-term durability even under demanding conditions.

This makes the Elpress shearbolt connector a versatile and maintenance-free choice for use in power distribution networks, industrial switchgear, and renewable energy installations.
