Shearbolt Connector SC150N

Benefits

✅ Easy installation – no special crimping tools required.
✅ Universal application – suitable for aluminium & copper conductors (class 1 & 2).
✅ Secure connection – shear-off bolts ensure correct tightening every time.
✅ Reliable performance – IEC 61238-1:2003 compliant.
✅ Versatile cable range – supports both round & sector-shaped conductors.
✅ Screen conductor support – compatible with SC150N/PEN filler piece.

The Shearbolt Connector SC150N (10–240 mm²) is designed for fast, safe, and reliable electrical connections without the need for hydraulic crimping tools. It features pre-threaded brass shear-off bolts, which minimize friction and guarantee consistent tightening, ensuring a durable and secure joint.

Engineered for 1 kV applications, the SC150N is suitable for both aluminium and copper conductors (class 1 and class 2). It accommodates round cables from 70–150 mm² and sector-shaped cables from 70–150 mm², providing flexibility in a wide range of power distribution projects.

Fully compliant with IEC 61238-1:2003, the connector meets international standards for reliability and performance. For splicing copper screen conductors in the range of 21–95 mm², the SC150N/PEN filler piece can be used, making it an ideal solution for safe and efficient screen conductor jointing.
